Descriptions
The equipment consists of main machine, assistant machine and control cabinet. The process of produce is continuous. The machine is extensively used in pharmaceutical, chemical, food industries for pulverizing dry brittle materials.
Technical paramenters
| spec | production capacity (Kg) | inlet material diameter(mm) | outlet material diameter(mesh) | Power (kw) | main rotating speed (r/min) | Overall dimension(LxWxH) (mm) | Weight (kg) |
| WFJ-15 | 10~200 | <10 | 80~320 | 13.5 | 3800~6000 | 4200*1200*2700 | 850 |
| WFJ-18 | 20~450 | <10 | 80~450 | 17.5 | 3800~6000 | 4700*1200*2900 | 980 |
| WFJ-32 | 60~800 | <15 | 80~450 | 46 | 3800~4000 | 9000*1500*3800 | 1500 |
-
