Technical parameters
| item | type | LPG－5 | LPG-25 | LPG-50 | LPG-100 | LPG-150 | LPG-200 | LPG-500 | LPG-800 | LPG-1000 | LPG-2000 | LPG-3000 | LPG-4500 | LPG-6500 |
| Water evaporation（kg/h） | 5 | 25 | 50 | 100 | 150 | 200 | 500 | ;800 | 1000 | 2000 | 3000 | 4500 | 6500 | |
| Spray type | Rotary atomozer | |||||||||||||
| Atomizer speed(r/min) | 25000 | 18000 | 16000 | 12000-13000 | 11000-12000 | |||||||||
| Atomizing diameter(mm) | 50 | 102 | 108 | 180-210 | 根据工艺要求确定 | |||||||||
| 塔体直径(m) | D | 0.9 | 1.75 | 2.3 | 2.7 | 3 | 3.2 | 4.7 | 5.6 | 6.2 | 根据工艺流程，厂地条件及用户要求确定 | |||
| 占地长度(m) | M | 1.6 | 4 | 4.5 | 5.2 | 7 | 7.5 | 12.5 | 13.5 | 14.5 | ||||
| 占地宽度(m) | L | 0.91 | 2.7 | 2.8 | 3.5 | 5.5 | 6 | 8 | 12 | 14 | ||||
| 塔体高度(m) | A | 1.75 | 4.5 | 5.5 | 6.7 | 7.2 | 8 | 1. | 11 | 15 | ||||
| 喷头吊装高度(m) | B | - | 2.5 | 2.5 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | ||||
| 注：水份蒸发量与物料特性，含固量及热风进出口温度有关。用户可根据当地能源情况选定加热方式，根据物料特性选择收尘，除尘方式。 | ||||||||||||||
Function descriptions：
Core components of atomizer: All high-precision bearings (SKF bearings,
Sweden), no-load vibration value ≤ 5μm load vibration value ≤ 15μm
Trouble-free operation: up to 7000 hours or more.
Atomizer total feeding quantity :5-15000kg / h.
Electrical control system: sub-levels, size, variety of control options
to meet different needs; classical logic approach; dynamic process
simulation system; FX-DU/WIN-C special software programming; PLC
control; configuration control; man-machine interface touch screen
operational control.
Pharmaceutical drying machine can be added: shaking, sweeping gas,
cooling jacket and other devices, piping all in compliance with GMP
requirements.
-
